Polycom Vortex EF2211 User Manual

This command sets the gain of the dial tone received from the phone interface.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are -20 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01GAINDT6
Set dial tone gain to 6 dB.
S01GAINDT6
S01GAINDT>3
Increase dial tone gain by 3 dB.
S01GAINDTx , where x is the new value of the dial
tone gain. If this command was issued after the
example above, then the status message would be
S01GAINDT9 .
S01GAINDT?
Query dial tone gain.
S01GAINDTx , where x is the new value of the dial
tone gain. If this command was issued after the
example above, then the status message would be
S01GAINDT9 .
8.57. GAINGIL -- Set Gain of Line Inputs as a Group
This command sets the gains of all the line inputs simultaneously. This is different from using a
wildcard, * with the
GAINI command because that command sets all the mic and line inputs together,
while the GAINGIL sets only the line inputs.
This command will generate acknowledgements from each of the line inputs separately.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are 0 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01GAINGIL7
Set gain of all line inputs to 7 dB.
S01GAINIA7
S01GAINIB7

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
