Polycom Vortex EF2211 User Manual

8.52. FPPSWD -- Change Front Panel Password
This command sets or queries the front panel password. This password is used in conjunction with the
FPLOCK command. The front panel must be unlocked ('FPLOCK0') in order to use this command to
set or query the front panel password. If the front panel is locked, then this command will result in
'ERROR#004'. The examples below assume that the front panel is unlocked.
Example Description Status Message
S01FPPSWDmonkey
Set front panel password to 'monkey'.
S01FPPSWDmonkey
S01FPPSWD?
Query the current front panel password.
S01FPPSWDmonkey
8.53. GAINA -- Set Phone Input Gain
This command sets the gain of the incoming signal from the phone interface. This command is an
alias for the
GAINIT command. It is provided for backwards compatibility with and ease of migration
from the EF200. When possible, the
GAINIT command should be used instead of this command.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are -100 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01GAINA6
Set phone input gain to 6 dB.
S01GAINA6
S01GAINA>3
Increase phone input gain by 3 dB.
S01GAINAx , where x is the new value of the
phone input gain. If this command was issued
after the example above, then the status message
would be S01GAINA9 .
S01GAINA?
Query phone input gain.
S01GAINAx , where x is the new value of the
phone input gain. If this command was issued
after the example above, then the status message
would be S01GAINA9 .
8.54. GAIND -- Set Gain of Incoming DTMF Tones
This command sets the gain of the incoming DTMF tones. The gain of the outgoing DTMF depends on
the country that the Vortex is configured for (see the
COUNTRY) command. This command is an alias
for the
GAINDIT command. It is provided for backwards compatibility with and ease of migration
from the EF200. When possible, the
GAINDIT command should be used instead of this command.

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
