Polycom Vortex EF2211 User Manual

S01NVPSWD?
Query the current non-volatile memory password.
S01NVPSWDlemur
8.114. PEQIA -- Set All Parameters for Specified Parametric
EQ Input Stage
This command sets or queries all of the parameters for the parametric equalizer (EQ) filters on input
channels 1, A, B, and T input channel T. Each channel has five bands of parametric EQ that can be
independently controlled.
The input parametric EQ filter parameters can be set individually via the
PEQIT, PEQIF, PEQIB,
PEQIG, PEQIS, and PEQIE commands. The output parametric EQ filter parameters can be set
simultaneously via the
PEQOA command or individually with the PEQOT, PEQOF, PEQOB, PEQOG,
PEQOS, and PEQOE commands.
When using this command, you must specify all of the following parameters.
Description Value Range Units
Channel 1, A, B, T N/A
Band 1-5 N/A
Filter Type 1-5
1 = parametric filter
2 = low shelf
3 = high shelf
4 = lowpass
5 = highpass
6 = Linkwitz-Riley lowpass
7 = Linkwitz-Riley highpass
Frequency 20 - 20000 Hz
Bandwidth 5 - 200 1/100th octave
Gain -20 - 20 dB
Slope
1 - 1.2 * Gain for shelving filters, 12 or 24 for Linkwitz-
Riley filters
dB per octave
Enable 0 - 1
0 = filter disabled
1 = filter enabled
The parameters are specified in the order shown and are separated by commas. The wildcard
character, *, may not be used for any of the parameters listed above. If an attempt is made to set
one of the parameters outside the valid range, the command will fail and return an error message of
ERROR#002.
Not all of the parameters are valid for each of the filter types. The following table shows which
parameters are used in each of the filter types.
Filter Type Bandwidth Frequency Gain Slope

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
