Polycom Vortex EF2211 User Manual

S01GAINO*äììä
Set gain on output channels 1
and T to 0 dB, and gain on
output channels A and B to 9 dB.
S01GAINO*äììä
S01GAINO*?
Query gain settings on all output
channels (1, A, B, T) .
S01GAINO*abcd, where a-d are each
between <space> and ÿ, depending on the
current setting of the gains for each of the ten
output channels (1, A, B, T).
8.60. GAINP -- Set Phone Output Gain
This command sets the gain of the output to the phone interface. This command is an alias for the
GAINOT. It is provided for backwards compatibility with and ease of migration from the EF200. When
possible, the
GAINOT command should be used instead of this command.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are -100 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01GAINP6
Set phone output gain to 6 dB.
S01GAINP6
S01GAINP>3
Increase phone output gain by 3 dB.
S01GAINPx , where x is the new value of the
phone output gain. If this command was issued
after the example above, then the status
message would be S01GAINP9 .
S01GAINP?
Query phone output gain.
S01GAINPx , where x is the new value of the
phone output gain. If this command was issued
after the example above, then the status
message would be S01GAINP9 .
8.61. GAINSIT -- Set From Phone User Tone Gain
This command sets the gain of the user tones coming from the phone DSP. User tones include entry
and exit tones (see
TONEE) and custom tones (see the SOUNDP and SOUNDL commands). In most
cases, the tones are played out "locally" and their gains are adjusted by the GAINSIT command.
Sometimes, the tones are played out to the phone, and the gain is adjusted by the
GAINSOT
command.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are -20 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
