S01DELAYOE*0110
Enable output delay on
outputs A and B, and disable
output delay on outputs 1 and
T.
S01DELAYOE*0110
S01DELAYOE*2
Toggle enabled status of
output delay on all outputs.
S01DELAYOE*abcd , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current enabled status of the output delay on
the corresponding output. If this command was
sent after the example above, then the status
message would be S01DELAYOE*1001 .
S01DELAYOE*?
Query enabled status of
output delay on all outputs.
S01DELAYOE*abcd , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current enabled status of the output delay on
the corresponding output. If this command was
sent after the example above, then the status
message would be S01DELAYOE*1001 .
8.43. DIAL -- Send DTMF Digits to Phone Interface
This command dials the specified string of digits by sending the equivalent DTMF tones to the phone
interface. Valid digits are '0'-'9', '*', '#', and ',' (delay). If the phone is not off-hook when this
command is executed, it will automatically be taken off-hook.
Example Description Status Message
S01DIAL9,,,4048921180
Dial 9 (to get an outside line), then pause (the three
commas), then dial 4048921180.
S10DIAL
8.44. DSPAUTO -- Enable Automatic DSPLOAD Status
Messages
This command sets or queries whether or not DSPLOAD messages will be automatically generated
whenever the DSP utilization changes.
This command is a boolean command. See
Section 6.1 for more information on this type of command.
Example Description Status Message
S01DSPAUTO1
Enable automatic DSPLOAD messages.
S01DSPAUTO1
S01DSPAUTO0
Disable automatic DSPLOAD messages.
S01DSPAUTO0
S01DSPAUTO2
Toggle automatic DSPLOAD messages.
S01DSPAUTOx , where x is 0 or 1
depending on the current setting of the
DSPAUTO paramter.
