Polycom Vortex EF2211 User Manual

S01VTXMODIB0
Disable VTX mode on input B.
S01VTXMODIB0
S01VTXMODIB2
Toggle status VTX mode on input
B.
S01VTXMODIBx , where x is either 0 or 1
depending on the current status of VTX mode
on input B.
S01VTXMODIA?
Query status of VTX mode on
input A.
S01VTXMODIAx , where x is either 0 or 1
depending on the current status of VTX mode
on input A.
S01VTXMODI*1
Enable VTX mode on inputs A-B.
S01VTXMODI*11
S01VTXMODI*0
Disable VTX mode on inputs A-B.
S01VTXMODI*00
S01VTXMODI*10
Enable VTX mode on input A and
disable VTX mode on input B.
S01VTXMODI*10
S01VTXMODI*2
Toggle status of VTX mode on
inputs A-B.
S01VTXMODI*ab , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current status VTX mode on the corresponding
input. If this command was sent after the
example above, then the status message
would be S01VTXMODI*01 .
S01VTXMODI*?
Query status of VTX mode on
inputs A-B.
S01VTXMODI*ab , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current status VTX mode on the corresponding
input. If this command was sent after the
example above, then the status message
would be S01VTXMODI*01 .
8.155. VTXMODO -- Enable VTX Mode on Specified Inputs
Vortex devices can be connected to a Polycom VTX 1000 in order to use the wideband capabilities of
that device. When connecting to a VTX 1000, special proccessing is done on the Vortex in order to
guarantee compatibility with the VTX 1000. This command enables processing for the VTX 1000 on
the specified line output or outputs.
This command is a channel boolean command. See
Section 6.3 and Section 6.1 for more information
on this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01VTXMODO11
Enable VTX mode on output 1.
S01VTXMODO11
S01VTXMODOA0
Disable VTX mode on output A.
S01VTXMODOA0
S01VTXMODO12
Toggle status VTX mode on
output 1.
S01VTXMODO1x , where x is either 0 or 1
depending on the current status of VTX mode
on output 1.

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
