3.4.1 Scanning Head
The scanning head is mounted on a light duty tripod with fluid head
(VIB-A-T02). The scanning head mounted on the light duty tripod with fluid
head is shown in the following figure.
Figure 3.11: Scanning head mounted on the light duty tripod with fluid head
CAUTION!
Risk of falling caused by loose locking mechanisms and screws! Loose screws may
cause the tripod to be unstable and possibly collapse. Tighten all screws of the tripod and the
trolley before you start mounting. Check all locking mechanisms for safety.
NOTE!
The M6 mounting screws of the scanning head may only be tightened with maximal 5Nm!
