3-16
3 First Steps
3.4.2 VIB-A-T02 Light Duty Tripod with Fluid Head
You can assemble the scanning head on the VIB-A-T02 tripod with fluid head.
To do so, proceed as follows:
1. Assemble the tripod as described in the assembly instructions provided by
the manufacturer MANFROTTO.
CAUTION!
Danger of crashing caused by insufficient safeguard measures! The scanning head
has a high inherent weight and may easily fall down from the tripod if it is not secured
appropriately. Carry out the disassembly of the scanning head only in pairs. Hold the
scanning head while a second person opens the safety lever.
2. Assemble the fluid head on the tripod as described in the assembly
instructions provided by the manufacturer MANFROTTO.
3. Open the locking mechanism on the fluid head by simultaneously pressing
the safety knob on the bottom side and moving the safety lever
counterclockwise to the end position.
4. A suitable hexagonal quick release plate has been pre-assembled on the
scanning head. Use the quick release plate to position the scanning head
on the fluid head.
The safety lever clicks into place automatically.
CAUTION!
Damage caused by unsecured tripod plate ! Snap the tripod plate all the way round.
Press the safety lever to the end position. Only then you can use the scanning head.
