Polytec PSV-500 User Manual

7-7
7 Technical Specifications
7.2.4 Data Acquisition (H System)
7.3 PSV-W-500-M PC
7.3.1 General Data
Mains Connection
Ambient Conditions
Industrial PC Housing
7.3.2 PC Configuration
Basic Set-Up
PSV
PSV-500-HM
(H system)
Data acquisition PSV-F-500-HM
Reference channels
4 (8)
1
1
The specifications in brackets are available as an option.
Maximum bandwidth 100kHz
Function generator PSV-F-500-HM
Output channels 4
Maximum bandwidth 100kHz
Mains voltage: 100…240VAC ±10%, 50/60Hz
Power consumption: max. 525VA
Protection class: 1 (protective grounding)
Operating temperature: +5°C…+40°C (41°F…104°F)
Storage temperature: − 10°C…+65°C (14°F …149°F)
Relative humidity: max. 80%, non-condensing
Dimensions (w x h x d): Without angle brackets
450mm x 190mm x 550 mm (19", 84HP / 4U)
With angle brackets
485mm x 190mm x 550mm (19", 84HP/4U)
Weight: 18 kg
Processor: min. Intel Core i7-2600K
Hard disk drive (HDD): > 1TB
Operating system: Microsoft® Windows® 7 (64-Bit) Ultimate
Network connection: Ethernet
DVD burner: refer to manufacturer's manual
