Polytec PSV-500 User Manual

7-8
7 Technical Specifications
7.3.3 Data Acquisition (M System)
7.4 PSV-E-530 Junction Box
7.4.1 General Data
Ambient Conditions
Housing
7.4.2 Signal Inputs and Outputs
REF 1 to REF 3
TRIG IN
PSV
PSV-500-HM
(M system)
Data acquisition PCI-6110
Reference channels 3
Maximum bandwidth
1MHz (2MHz)
1
1
The designations in brackets are available as an option.
Function generator M2i.6030
Output channels 1
Maximum bandwidth
1MHz (2MHz)
1
Operating temperature: + 5°C…+40°C (41°F…104°F)
Storage temperature: − 10°C … + 65°C (14°F …149°F)
Relative humidity: max. 80%, non-condensing
Protection rating: IP20
Dimensions (w x h x d): 482mm x 44.5mm x 320mm
Weight: 1.1kg
Input voltage range: ±200mV…±10 V
Input impedance: 1MΩ, in parallel with 100pF
Input coupling: AC/ DC, adjustable in the software
AC –3dB cutoff frequency: 0.05Hz
Overvoltage protection: ±42 V (against damage)
Compatibility: TTL/ CMOS
Overvoltage protection: ±15 V (against damage)
Input resistance: 10kΩ
