Polytec PSV-500 User Manual

3-7
3 First Steps
6REF1 signal output (BNC jack)
Connection for the AI_1 line of the ACQ HM acquisition cable from the PC
7 Connection for cable shielding (blade connector)
Connection for the shielding line of the ACQ HM acquisition cable
3.3.3 PSV-W-500-M PC
Front view The front view of the PC is shown in the following figure. The lockable front
flap is shown transparently.
Figure 3.5: Front view of the PC
1 Cooling fan
2 Power L ED
L
ED green: ready to operate
3 HDD L ED
L
ED yellow: hard disk drive (HDD) in the PC is active
4 RESET key
Reset and restart PC
5 DVD burner
You will find an exact description of the DVD burner in the manufacturer's
manual.
6POWER key
Switch on / off the device
7 USB interface (Universal Serial Bus, type A)
Connection for a mass storage device
POWER
RESET
DMS
DATA MANAGEMENT SYSTEM
1
5
6
2
3
4
7
8
