7-11

7 Technical Specifications

Dimensions

Figure 7.1: Dimensions of the scanning head (Dimensions not specified are given in mm.)

M68(2x)

103

150

370

Beam

0.6

4.5

Stand-off distance

120

103

120

177

Ø4
