Polytec PSV-500 User Manual

A-3
A Optional Accessories
A.2 PSV-A-T11 Motorized Pan-Tilt Head
A.2.1 Assembly
You can assemble the scanning head onto a heavy tripod with motorized pan-
tilt head PSV-A-T11. You can mount the heavy duty tripod on a trolley
(optional).
Assembly kit Unpack the tripod and check the contents of the assembly kit:
Approach You can assemble the scanning head onto the PSV-A-T11 tripod with
motorized pan-tilt head. To do so, proceed as follows:
1. Attach the mounting plate on the bottom of the scanning head with the two
M6 x 16 countersunk screws as show in the following figure. To do this,
use the size 4mm Allen key.
CAUTION!
Damage caused by assembly error! Always tighten all screws securely so that stability
and functional accuracy of the system are ensured!
NOTE!
Mount the sides labeled with FRONT in the direction of the front of the scanning head.
1 mounting plate with 2 M6x 16 countersunk screws
1 adapter plate with 3 M6x20 Allen screws
1 connector box with 4 M8x40 Allen screws
3 M8x16 Allen screws with washers
2 M6x16 Allen screws with washers
1 size 4mm Allen key
1 size 5mm Allen key
1 size 6mm Allen key
