24
PORA ELECTRIC MACHINERY CO.,LTD.
Tension Controller
7. Button lock function
※ If using this button lock function of a controller, it can prevent mal-operation by carelessness of a user in
advance.
0.0kg
0.0kg
0.0mpm 100.0mm
T
5.8%
~
[ Lock button ]
1) When pressing [Lock button] longer in automatic mode or manual mode, button lock function vitalizes and the
button does not work. (Only lock button works)
2) LED at the upper of [Lock button] is on, lock icon will be shown on a display.
3) When pressing [Lock button] longer again while lock function is working, it is unlocked.
8. Remote function
※ When hoping to control a controller using digital contact point or communication from outside, please use this
function.
0.0kg
0.0kg
0.0mpm 100.0mm
T
OFF
~
Remote activated!
[ Fn button ]
1) When pressing [Fn button] longer at front operational part in automatic or manual mode, remote function starts
to work. Remote LED is on and an Icon for remote contact point is shown on a screen.
2) A button of a controller can not be read depending on the way of setting of digital input contact point.
3) When pressing [Fn button] longer again, remote function does not work.
4) When using communication function except for hyper terminal, remote function has to be activated.
(When using communication, digital input is not read.)
5) It is always able to set remote function to be working when turning the powder using initial operation mode
function.
To Next Page
