Item Specification
Display 3.2 inch Full Color TFT-LCD
Output
Control 0~24Vdc / 4.5A PWM type
Analog
Selectable between Control Output 0~10Vdc, -10~+10Vdc, 4~20mA, 0~20mA
Selectable between Tension Output 0~10Vdc, 4~20mA
Digital
6 Channels (24Vdc/150mA Open Collector)
Selectable between Auto, Manual, Output On, Tension Zero, Emergency Stop, Control
Shaft, The upper limit of control, the lower limit of control, Sensor error,
Tension error and Maximum diameter operation.
Input
Analog
3 channels (Selectable between 0~10Vdc, 4~20mA)
Selectable between target tension, manual output, line speed,
input diameter operation and dancer roll.
In case of using external volume, 2kΩ~10kΩ is recommended.
Digital
6 Channels (24Vdc/15mA)
Selectable between Auto, Manual, Output On, Tension Zero, Emergency Stop,
Shaft switch and initialization of operation diameter
Control Speed 5ms
Range of Tension
measurement
-9,999 ~ 99,999kg
Communication Hyper terminal (RS-232), Modbus-RTU (RS-232), Ethernet, CAN 2.0A
Power
Input 100~240Vac +/-10%, 50/60Hz (Single Phase)
Output
24Vdc / 0.5A Power for sensor pulse
5Vdc / 50mA Power for external volume
5Vdc / 1A Power for tension detector
Power consumption 120VA
Operation temperature 0℃~65℃
Weight 3kg
Sensor Model
PRTL (Load cell) PRTL-A, PRTL-AB, PRTL-B, PRTL-C, PRTL-D, PRTL-E, PRTL-PA
PR-LX (Pickup) PR-LX-030TD, PR-LX-050TD, PR-100TD
PRTP (Differential Pickup) PRTP-2T, PRTP-3T, PRTP-5T
5. Compatible Sensor
4. Product Specifications
※Besides, it is able to input tension detecting sensor ranging from 1mV/V~35mV/V.
