3. Product installation & Wiring
Combine a bracket with a main body and tighten a screw to fix the position a user hopes.
4.2
< Fixed type >
< Panel mount type >
1) How to install a controller
- Please use solderless terminal like same sized one of below image.
- Please tighten certainly not to cause malfunction.
- Input/output wiring should be wired through DUCT which is same as other power line and shouldn’t be tied
together.
2) Block arrangement
A controller can be installed with various way like below. Please install it where there is convenience and easy to
maintenance.
It is recommended to install the controller on a place where is
convenient to use and easy to maintain and repair.
To Next Page
