PORA PR-DTC-4100.AD - The Rest; Sheet for Recording Internal Setting

43
PORA ELECTRIC MACHINERY CO.,LTD.
PR-DTC-4100.A / AD
Setting menu item Submenu item
Modbus address
Setting range (Setting item) Initial setting Setting values
Int Hex
1. BASIC SET
1. TENSION UNIT 40001 9C41 kg, N kg
2. MAIN DISPLAY 40002 9C42 BAR GRAPH, TREND GRAPH, DATA BAR GRAPH
3. 언어/LANGUAGE 40003 9C43
한국어 (KOREAN),
ENGLISH, 中文 (CHINESE)
한국어 (KOREAN)
4. START OPERATION 40004 9C44 LOCAL, REMOTE LOCAL
5. OP. MEMORY 40005 9C45 USE, UNUSE USE
6. DEFAULT RESET 40006 9C46 NO, EXVEPT CALI, ALL RESET NO
2. TENSION
CALIBRATION
1. SENSOR SELECT 40011 9C4B
PRTL, PRLX, PRTP,
DANCER ROLL
PRTL
2. SENSOR SIG(mV/V) 40012 9C4C 1.0~35.0 3.0
3. FULL SCALE(kg,N) 40013 9C4D 0~20000 100
4. CAL.TENSION(kg,N) 40014 9C4E 0~20000 30
5. ZERO INPUT(BCD) 40015 9C4F -32767~32767 / -32767~32767 0 / 0
6. SPAN INPUT(BCD) 40016 9C50 -32767~32767 / -32767~32767 4095 / 4095
7. CALI. SCALE(%) 40017 9C51 0.0~1000.0 100.0
3. TENSION
CONTROL
1. TENSION ZONE 40021 9C55 UNWIND, REWIND UNWIND
2. ZERO RANGE(% FS) 40022 9C56 0.0~10.0 0.5
3. TENSION LMT(% FS) 40023 9C57 0.0~100.0 100.0
4. TENSION HI(% FS) 40024 9C58 0.0~100.0 100.0
5. TENSION LOW(% FS) 40025 9C59 0.0~100.0 0.0
6. M/A CHANGE 40026 9C5A UNUSE, USE UNUSE
7. TAPER USE 40027 9C5B
UNUSE, MANU-->AUTO,
MANU<--AUTO, MANU<->AUTO
UNUSE
4. CONTROL
OUTPUT
1. CONTROL REEL 40031 9C5F A, B A
2. CONTROL POL. 40032 9C60 NORMAL, REVERSE NORMAL
3. EXCITATION(% RO) 40033 9C61 0.0~100.0 5.0
4. OUTPUT LMT(% RO) 40034 9C62 0.0~100.0 100.0
5. PRE OUT-A(% RO) 40035 9C63 0.0~100.0 50.0
6. PRE OUT-B(%RO) 40036 9C64 0.0~100.0 50.0
7. REEL CHANGE(sec) 40037 9C65 0.0~100.0 5.0
8. CHANGE COMP.(sec) 40038 9C66 0.0~999.9 5.0
5. PID SET
1. P GAIN 40041 9C69 0.0~10.0 0.3
2. I GAIN 40042 9C6A 0.0~10.0 0.5
3. D GAIN 40043 9C6B 0.0~10.0 0.1
6. ANALOG
INPUT SEL.
1. ANALOG 1 40051 9C73
UNUSE, TENSION, TORQUE,
LINESPEED, DIAMETER,
DANCEDR ROLL
UNUSE
2. ANALOG 1 INPUT 40052 9C74 0...10V, 4...20mA 0...10V
3. ANALOG 2 40053 9C75
UNUSE, TENSION, TORQUE,
LINESPEED, DIAMETER,
DANCEDR ROLL
UNUSE
4. ANALOG 2 INPUT 40054 9C76 0...10V, 4...20mA 0...10V
1. Sheet for recording internal setting
The rest
Reporting date: Company name:
Product s/n no. : Person in charge :
