PORA ELECTRIC MACHINERY CO.,LTD.

Tension Controller

PR-DTC-4100.A / AD

Setting menu item Submenu item

Modbus address

Setting range (Setting item) Initial setting Setting values

Int Hex

6. ANALOG

INPUT SEL.

5. ANALOG 3 40055 9C77

UNUSE, TENSION, TORQUE,

LINESPEED, DIAMETER,

DANCEDR ROLL

UNUSE

6. ANALOG 3 INPUT 40056 9C78 0...10V, 4...20mA 0...10V

7. ANALOG

INPUT SET

1. REF.ZERO(BCD) 40061 9C7D 0~16383 0

2. REF.SPAN(BCD) 40062 9C7E 0~16383 16383

3. OFFSET(%) 40063 9C7F 0.0~100.0 0.0

4. SPAN(xN) 40064 9C80 0.0~10.0 1.0

5. TRQ.ZERO(BCD) 40065 9C81 0~16383 0

6. TRQ.SPAN(BCD) 40066 9C82 0~16383 16383

7. OFFSET(%) 40067 9C83 0.0~100.0 0.0

8. SPAN(xN) 40068 9C84 0.0~10.0 1.0

8. LINESPEED

1. LINESPEED INPUT 40071 9C87 TG, ANALOG TG

2. SPEED MIN(mpm) 40072 9C88 0.0~1000.0 0.0

3. SPEED MIN(BCD) 40073 9C89 0~16383 0

4. SPEED MAX(mpm) 40074 9C8A 0.0~1000.0 200.0

5. SPEED MAX(BCD) 40075 9C8B 0~16383 16383

6. M/A MODE CHANGE 40076 9C8C UNUSE, USE UNUSE

7. CHANGE REF.(mpm) 40077 9C8D 0.0~1000.0 15.0

9. TAPER

1. DIAMETER INPUT 40081 9C91 PULSE, ANALOG ANALOG

2. THICKNESS(um) 40082 9C92 0.0~2000.0 100.0

3. REEL PULSE 40083 9C93 1, 2, 4, 8 1

4. TAPER RATIO(%) 40084 9C94 0.0~100.0 100.0

5. DIAMETER MIN(mm) 40085 9C95 0.0~2000.0 100.0

6. DIAMETER MIN(BCD) 40086 9C96 0~16383 0

7. DIAMETER MAX(mm) 40087 9C97 0.0~2000.0 1000.0

8. DIAMETER MAX(BCD) 40088 9C98 0~16383 16383

10. ANALOG

OUTPUT

1. CONTROL OUTPUT 40091 9C9B

0...5V, 0...10V, -10...+10V,

4…20mA, 0...20mA

0...10V

2. CONTROL POLARITY 40092 9C9C NORMAL, REVERSE NORMAL

3. CONTROL LMT(% RO) 40093 9C9D 0.0~100.0 100.0

4. TENSION OUTPUT 40094 9C9E

0...5V, 0...10V,

4...20mA, 0...20mA

0...10V

5. TENSION POLARITY 40095 9C9F NORMAL, REVERSE NORMAL

11. DIGITAL

INPUT

1. DIGITAL 1 40101 9CA5
