7. ANALOG INPUT SET
It is able to set analog input items.
1) REF. ZERO(BCD): It is to set the minimum values of analog input
signal for target tension.
- Input range: 0 ~ 16383
2) REF. SPAN(BCD): It is to set the maximum values of analog input
signal for target tension.
- Input range: 0 ~ 16383
3) OFFSET(% FS): It is to set the offset values which will add to target
tension. (Analog input signal).
- Setting range: 0.0 ~ 100.0
4) SPAN(xN): Please do multiply values which is set to target tension.
(Analog tension value)
- Setting range: 0.0 ~ 10.0
5) TRQ. ZERO(BCD): Please input the minimum values of analog input
signal for manual output.
- Input range: 0 ~ 16383
6) TRQ. SPAN(BCD): Please input the maximum values of analog input
signal for manual output.
- Input range: 0 ~ 16383
7) OFFSET(% FS): It is to set the offset values which will add to manual
output. (Analog input signal)
- Setting range: 0.0 ~ 100.0
8) SPAN(xN): Please do multiply the values which is set to manual
output. (Analog input signal)
- Setting range: 0.0 ~ 10.0
1. REF. ZERO(BCD) 2. REF. SPAN(BCD)
3. OFFSET(% FS) 4. SPAN(xN)
5. TRQ. ZERO(BCD) 6. TRQ. SPAN(BCD)
0.0
0
163830
7. OFFSET(% RO)
0.0
8. SPAN(xN)
1.0
1.0
16383
7. ANALOG INPUT SET
ESC CLR SET SELECT
