2. External connection diagram
DO1Digital output 1
Digital output 2
1
DO2 2
Digital output 3 DO3 3
Digital output 4 DO4 4
Digital output 5 DO5 5
Digital output 6 DO6 6
Digital output COM COM 7
+
-
+
-
+
-
249Ω
SW
249Ω
SW
249Ω
SW
+
-
AI1+Analog input 1+ 21
AI1-Analog input 1- 22
AI2+Analog input 2+ 23
AI2-Analog input 2- 24
AI3+Analog input 3+ 25
AI3-Analog input 3- 26
TG+TG input + 27
TG-TG input - 28
FG 29
Power for sensor PWM 30
Power for sensor PWM 34
Sensor input 3+ SIG3+ 31
Sensor input 4+ SIG4+ 35
Sensor input 4- SIG4- 36
Sensor input 3- SIG3- 32
FG 33
5V
+5V 19
GND 20
+
-
+
-
VO1 Voltage output for control37
IO1 Current output for control39
IO2 Current output for tension42
VO1 Voltage output for tension40
GND38
GND41
RS232
TX43
GND45
RX44
120Ω
CAN
Terminating
resistance
H46
L47
R148
R249
FG50
5V
5V
EXC1+ Power for sensor51
EXC2+ Power for sensor56
EXC2- Power for sensor57
EXC1- Power for sensor52
SIG1+ Sensor input 1+53
SIG1- Sensor input 1-54
FG55
SIG2+ Sensor input 2+58
SIG2- Sensor input 2-59
V+
V+
FUSE 7A
Driver A
Driver B
PA60
PB62
NA61
NB63
24Vdc/4.5A
24Vdc/4.5A
Only
PR-DTC-4100.AD
FUSE T1.6A
VCC
VEE
5V
V+
L Power65
N Power66
ANALOG
OUTPUT
RS-232
(Modbus-RTU)
CAN
SENSOR
INPUT1
POWDER
BRAKE
&
POWDER
CLUTCH
100~240Vac
FG64
METAL
PLATE
V+
V+
DI1 8
DI2 9
DI3 10
DI4 11
DI5 12
+24V
Power (24V)
Sensor signal
Ground
16
SIG 17
GND 18
DI6 13
COM 14
FG 15
Digital input 1
Digital input 2
Digital input 3
Digital input 4
Digital input 5
Digital input 6
Digital input COM
DIGITAL
OUTPUT
ANALOG
INPUT
SENSOR
INPUT2
(For
differential
pickup)
Power for
external
volume
DIGITAL
INPUT
PRX
