8. LINE SPEED
It is able to set the items related line speed.
1) LINESPEED: It is to select the signal which can check line speed.
●
Select item: TG, ANALOG
- TG: It uses TG input terminal.
- ANALOG: It uses 1 channel of 3 channels of analog input.
2) SPEED MIN(mpm): It is to set the lowest values of line speed input
signal.
- Setting range: 0.0 ~ 1000.0
3) SPEED MIN(BCD): It is to input analog values at lowest speed which
is set-up the above No.2 item.
- Input range: 0 ~ 16383
4) SPEED MAX(mpm): It is to set the maximum values of line speed
input signal.
- Setting range: 0.0 ~ 1000.0
5) SPEED MAX(BCD): It is to input analog values at maximum speed
which is set-up the above No.4 item.
- Input range: 0 ~ 16383
6) M/A MODE CHANGE: It is to set whether to switch manual/automatic
mode or not by using line speed.
- Select item: UNUSE, USE
7) CHANGE REF.(mpm): It is to set the line speed which switches the
mode.
- Setting range: 0.0 ~ 1000.0
- If line speed is higher than set-up values, manual mode will be
switched to automatic mode and if it is lower than set-up values,
automatic mode will be switched to manual mode.
M/A MODE CHANGE - USE
An icon shown on a screen
1. LINESPEED 2. .SPEED MIN(mpm)
3. SPEED MIN(BCD) 4. SPEED MAX(mpm)
5. SPEED MAX(BCD) 6. M/A MODE CHANGE
0
TG
UNUSE16383
7. CHANGE REF.(mpm)
15.0
200.0
0.0
8. LINESPEED
ESC CLR SET SELECT
