User’s Manual 11
1. Mobile Computer Slot
Put the mobile computer in the cradle slot for data transmission or charging
2. Power LED Indicator
LED status Description
Green Power on (mobile computer not in cradle)
3. Charging LED Indicator
LED status Description
Red Charging
Green Charging complete
4. RS232 / USB and Charging Connector
Connects the multiple function socket on the mobile computer for data transmission and
charging
5. Charging Slot
For charging a spare rechargeable battery pack
6. RS-232 C Socket
For connecting to PC serial port through standard RS232 cable
7. USB Socket
For connecting to PC USB port through a standard USB cable
8. DC Input Socket
Input for AC adapter
