User’s Manual 4
1.3 Specifications
Performance
OS Windows CE .NET 4.2
CPU Intel PXA-270 (520 MHz)
RAM 64MB SDRAM
ROM 128MB
Display
LCD 3.5” Color TFT LCD with touch panel
Resolution 240 x 320
Scanner
Scanner system Long range CCD scanner 2048 pixels
Resolution 4 mil (0.10mm) min. at PCS 90%
Depth of field 15.5” (UPC/EAN, 13 mil at PCS 90%)
Scanning rate 400 scans/sec
PCS
!30%
Ambient light 0~20,000 lux
Readable barcode Code 39, Code 93, Code 11, Code 128, EAN-128, Codabar, UPC
A/E, EAN 8/13, UK Plessey, MSI/Plessey, Standard 2 of 5,
Interleaved 2 of 5, Telepen, Matrix 2 of 5, China Post Code
Keypad
23 keys with back light
Communication Interface
Standard Interface RS232 & USB
Power supply
Main power Rechargeable Li-ion Battery
3600mAH, 3.7Vdc
Power input Via cradle or direct charging
* Batteries must be charged at a temperature ranging from 0~+45°C (+32°F to +113°F). At
temperatures below 0°C and above +45°C display or battery performance degradation may
occur.
