POSline TPC7050 - Cradle

User’s Manual 10
2.2.2 Cradle
Dimensions of the CRD-80 Cradle
117.5mm (L) x 113.5mm (W) x 70.5mm (H)
Details of the CRD-80 Cradle
Front
Figure 2-5 The Front of the CRD-80
Back
Figure 2-6 The Back of the CRD-80
Power Charging
Mobile
RS232/USB and charging
Charging slot
Power
RS-232 port
USB port
