SD450 - DEVICENET POWER ELECTRONICS
12
INTRODUCTION
1. INTRODUCTION
1.1. Description of the DeviceNet Optional Board
The optional board for DeviceNet communication allows SD450 drive
to connect it to a DeviceNet network. Thanks to this optional board:
Inverter can be controlled and monitored by PLC sequence
program or any master module.
Multiple inverters can be connected to one communication cable
with simple and easy installation, saving wiring, maintenance cost
and time.
Compatible with PC System, PLC and any controllers is available,
making Factory Automation more easily.
1. DeviceNet Connector
2. Status Leds
3. Inverter Connector
3
1
2
