TECHNICAL CHARACTERISTICS
2.1.3. Local Indications
LED Description Function
MS Module Status
It supplies information about the status of
incoming power to optional board, CPU function
and communication to the inverter.
NS Network Status
It supplies information about the connection of
optional board on the network and DeviceNet
power status.
Note: See section ‘6. FAULT DIAGNOSIS’ to obtain more detailed
information of Status Leds.
