9.6. Group COM (Communications)
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9600 38400
COM-00
Jump Code
Jump to desired parameter 1 1 – 99
9601 38401
COM-01
Opt B/D
Communications board type - DeviceNet
None
Command
Freq
9602 38402
COM-02
Opt mode
Mode option 0
Cmd+Freq
0 – 3
9603 38403
COM-03
Opt Version
Version -
960A 38410
COM-10
MAC ID
DeviceNet ID 63 0 – 63
125 kbps
250 kbps
960B 38411
COM-11
Baud Rate
DeviceNet network speed
500 kbps
0 - 2
20
21
100
960C 38412
COM-12
Out Instance
DeviceNet output instance 20
101
0 – 3
70
71
110
960D 38413
COM-13
In Instance
DeviceNet input instance 70
111
0 – 3
8None/1Stop
8None/2Stop
8Even/1Stop
963C 38460
COM-60
Parity/Stop
Parity Bit / Stop Bit 0
8Odd/1Stop
0 – 3
