POWER ELECTRONICS SD450 - DEVICENET
ADDRESS LIST
53
ENGLISH
9.5. Group I/O (Inputs and Outputs Menu)
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9400 37888
I/O-00
Jump code
Jump to desired parameter 1 1 – 99
9401 37889
I/O-01
V1 Filter
Filter of analogue voltage input 250 0 – 9999
9402 37890
I/O-02
V1 volt x1
Minimum voltage of V1 input 0 0 – I/O-4
9403 37891
I/O-03
V1 Freq y1
Minimum frequency for
minimum voltage of V1 input
0
0 – FU1-
30
9404 37892
I/O-04
V1 volt x2
Maximum voltage of V1 input 1000
I/O-2 –
1200
9405 37893
I/O-05
V1 Freq y2
Maximum frequency for
maximum voltage of V1 input
5000
0 – I/O-
03
9406 37894
I/O-06
I Filter
Filter of analogue current input 250 0 – 9999
9407 37895
I/O-07
I curr x1
Minimum current of I input 400 0 – I/O-9
9408 37896
I/O-08
I Freq y1
Minimum frequency for
minimum current of I input
0
0 – FU1-
30
9409 37897
I/O-09
I curr x2
Maximum current of I input 1000
I/O-7 –
2000
940A 37898
I/O-10
I Freq y2
Maximum frequency for
maximum current of I input
5000
0 – I/O-
08
(A+B)
940B 37899
I/O-11
P pulse set
Selection of pulse input mode 1
(A)
0 – 1
940C 37900
I/O-12
P Filter
Filter of pulse input 10 0 – 9999
940D 37901
I/O-13
P pulse x1
Minimum pulse frequency of
A0, B0 input
0
0 – I/O-
15
940E 37902
I/O-14
P Freq y1
Minimum freq. for minimum
pulse frequency of A0, B0 input
0
0 – FU1-
30
940F 37903
I/O-15
P pulse x2
Maximum pulse frequency of
A0, B0 input
0
I/O-13 –
100
9410 37904
I/O-16
P Freq y2
Maximum freq. for maximum
pulse frequency of A0, B0 input
5000
0 – I/O-
14
None
Half of x1
9411 37905
I/O-17
Wire broken
Criterion for signal loss of
reference analogue input
0
Less than x1
0 – 2
None
FreeRun
9412 37906
I/O-18
Lostcommand
Stop mode after analogue input
signal loss
0
Stop
0 – 2
