Power Electronics SD450 Series User Manual

SD450 - DEVICENET POWER ELECTRONICS
54
ADDRESS LIST
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9413 37907
I/O-19
Time out
Delay time after reference
signal loss
10 1 – 1200
Speed-L
Speed-M
Speed-H
XCEL-L
XCEL-M
XCEL-H
DC-brake
2nd Func
Exchange
Reserved
Up
Down
3-Wire
Ext Trip
Pre-Heat
iTerm Clear
Open-loop
Main-drive
Analog
hold
XCEL stop
P Gain2
Reserved
Interlock1
Interlock2
Interlock3
Interlock4
Speed-X
RST
BX
JOG
FX
RX
ANA_CHG
Pre-Excite
Ext PID
Run
9414 37908
I/O-20
M1 define
Multi-function digital input. M1
terminal
0
Up/Dn Clr
0 – 35
