POWER ELECTRONICS SD450 - DEVICENET

ADDRESS LIST

ENGLISH

Address Range

16 bit 10 bit

Screen Description

Default

value

Option Values

9415 37909

I/O-21

M2 define

Multi-function digital input. M2

terminal

0 See I/O-20 0 – 35

9416 37910

I/O-22

M3 define

Multi-function digital input. M3

terminal

1 See I/O-20 0 – 35

9417 37911

I/O-23

M4 define

Multi-function digital input. M4

terminal

27 See I/O-20 0 – 35

9418 37912

I/O-24

M5 define

Multi-function digital input. M5

terminal

28 See I/O-20 0 – 35

9419 37913

I/O-25

M6 define

Multi-function digital input. M6

terminal

29 See I/O-20 0 – 35

941A 37914

I/O-26

M7 define

Multi-function digital input. M7

terminal

30 See I/O-20 0 – 35

941B 37915

I/O-27

M8 define

Multi-function digital input. M8

terminal

31 See I/O-20 0 – 35

941C 37916

I/O-28

In status

Digital inputs status

0 (Bit

display)

0 – 2047

(Bit

display)

941D 37917

I/O-29

Ti Filt Num

Filter of digital inputs 15 2 – 1000

941E 37918

I/O-30

Jog Freq

Setting of jog frequency 1000

0 – FU1-

941F 37919

I/O-31

Step Freq-4

Speed at step frequency 4 4000

0 – FU1-

9420 37920

I/O-32

Step Freq-5

Speed at step frequency 5 5000

0 – FU1-

9421 37921

I/O-33

Step Freq-6

Speed at step frequency 6 4000

0 – FU1-

9422 37922

I/O-34

Step Freq-7

Speed at step frequency 7 3000

0 – FU1-

9423 37923

I/O-35

Step Freq-8

Speed at step frequency 8 2000

0 – FU1-

9424 37924

I/O-36

Step Freq-9

Speed at step frequency 9 1000

0 – FU1-

9425 37925

I/O-37

Step Freq-10

Speed at step frequency 10 2000

0 – FU1-

9426 37926

I/O-38

Step Freq-11

Speed at step frequency 11 3000

0 – FU1-

9427 37927

I/O-39

Step Freq-12

Speed at step frequency 12 4000

0 – FU1-

9428 37928

I/O-40

Step Freq-13

Speed at step frequency 13 5000

0 – FU1-

9429 37929

I/O-41

Step Freq-14

Speed at step frequency 14 4000

0 – FU1-
