SD450 - DEVICENET POWER ELECTRONICS

FAULT DIAGNOSIS

6.2. MS Led (Module Status)

LED Status Cause Diagnostic

OFF

Off-Line

(no power)

5V power supply is not

applied to the DeviceNet

board.

Check the incoming power to inverter is

provided.

Solid

Green

Operational Normal operation state.

Solid

Red

Unrecovera

ble fault

Data transaction through

DPRAM is disrupted.

Check the connection between DeviceNet

board and inverter.

Flashing

Green and

Red

Self-test

Device is in self-test

mode.
