POWER ELECTRONICS SD450 - DEVICENET
DEVICENET DATA TABLES
29
ENGLISH
Attribute ID Attribute Name Access Method
5
Allocation Information:
Allocation Choice Byte
4
Master’s MAC ID
R
6 MAC ID Switch Changed R
7 Baud Rate Changed Not Support
8 MAC ID Switch Value Not Support
9 Baud Rate Switch Value Not Support
Implemented for:
Service Name Service Code
Class Instance
Get_Attribute_Single 0x0E Yes Yes
Set_Attribute_Single 0x10 No Yes
Allocate Master/Slave
Connection Set
0x4B No Yes
Release Group 2
Identifier Set
0x4C No Yes
7.1.3. Class 4 – Assembly Object
Class Code 0x04
Instance 1 (All Attributes are instance 1)
1
Allocation Choice Byte
7 6 5 4 3 2 1 0
Not Support Polled
Explicit
Message
