DEVICENET DATA TABLES
Attribute ID Attribute Name Access Method
1 Vendor ID R
2 Device Type R
3 Product Code R
Revision R
Major Revision (High Byte)
4
Minor Revision (Low Byte)
5 Status
1
R
6 Serial Number R
7 Product Name R
7.1.2. Class 3 – DeviceNet Object
Class Code 0x03
Instance 1 (All attributes are instance 1)
Attribute ID Attribute Name Access Method
1 MAC ID
2
R/W
2 Baud Rate
3
R/W
3 BOI Not Support
4 Bus-Off Counter Not Support
1
Status Attribute
Bit Number 0 (Owned) 8 (Recoverable Minor Fault) Other bits
Meaning
Connected to the master
DPRAM Error Not Support
2
Range of MAC ID: 0 – 63.
3
Baud Rate
Value 0 1 2
Baud Rate 125kbps 250kbps 500kbps
