DEVICENET DATA TABLES
7.1.4. Class 5 – Connection Object
Class Code 0x05
1 Predefined EMC
2 Poll E/S
Instance
6, 7, 8, 9, 10 Dynamic EMC
Access Method
I/O EMC
Attribute ID Attribute Name
Established / Time Out
Established /
Deferred Delete
1 State R R
2 Instance Type R R
3 Transport Class Trigger R R
4 Produced Connection ID R/W R
5 Consumed Connection ID R/W R
6
Initial Communication
Characteristics
R R
7 Produced Connection Size R R
8 Consumed Connection Size R R
9 Expected Packed Rate R/W R/W
10 – 11 Not Available
12 Watchdog Timeout Action R/W R/W
13
Produced Connection Path
Length
R R
14 Produced Connection Path R R
15
Consumed Connection Path
Length
R R
16 Consumed Connection Path R R
17 Production Inhibit Time R/W R
