POWER ELECTRONICS SD450 - DEVICENET
DEVICENET DATA TABLES
33
ENGLISH
Implemented for:
Service Name Service Code
Class Instance
Get_Attribute_Single 0x0E No Yes
Reset 0x05 No Yes
Set_Attribute_Single 0x10 No Yes
7.1.5. Class 28 – Motor Data Object
Class Code 0x28
Instance 1 (All attributes are instance 1)
Attribute ID Attribute Name Access Method
3 Motor type R
6
6 Rated current R/W
7 Rated voltage R
Implemented for:
Service Name Service Code
Class Instance
Get_Attribute_Single 0x0E No Yes
Set_Attribute_Single 0x10 No Yes
6
Motor type Attribute – Squirrel Cage Induction Motor: #7.
