POWER ELECTRONICS SD450 - DEVICENET
ADDRESS LIST
39
ENGLISH
9. ADDRESS LIST
9.1. Common Area
Address Parameter Scale
Units
R/W Data value
0x0000 Inverter model R 9: SD450
0x0001 Inverter capacity R
3: 3.7kW
4: 5.5kW
5: 7.5kW
6: 11kW
7: 15kW
8: 18.5kW
9: 22kW
A: 30kW
B: 37kW
C: 45kW
D: 55kW
E: 75kW
0x0002 Inverter input voltage R
0: 220Vac
1:440Vac
0x0003 SW version R
(Ex) 0x0100: Version 1.0
(Ex) 0x0101: Version 1.1
0x0004
Parameters setting
enabled/disabled
R/W
0: Write disabled
1: Write enabled
0x0005 Reference frequency 0.01 Hz R/W Start freq. to Max. freq.
