Power Electronics SD450 Series User Manual

SD450 - DEVICENET POWER ELECTRONICS
30
DEVICENET DATA TABLES
Implemented for:
Service Name Service Code
Class Instance
Get_attribute_Single 0x0E No Yes
Set_Attribute_Single 0x10 No Yes
Output Assembly Data Attribute Format
Instance
Bit
Byte
7 6 5 4 3 2 1 0
0
Fault
Reset
Run
Fwd
1
2
Speed Reference (Low Byte) – RPM
(Speed Reference (Low Byte) – Hz)
20
(100)
3
Speed Reference (High Byte) – RPM
(Speed Reference (High Byte) – Hz)
0 NetRef NetCtrl
Fault
Reset
Run
Rev
Run
Fwd
1
2
Speed Reference (Low Byte) – RPM
(Speed Reference (High Byte) – Hz)
21
(101)
3
Speed Reference (Low Byte) – RPM
(Speed Reference (High Byte) – Hz)
Related Attribute
Name Description
Class Attribute ID
Run Fwd Forward Run Command 0x29 3
Run Rev Reverse Run Command 0x29 4
Fault Reset Fault Reset Command 0x29 12
NetRef
5
Not Used 0x2A 4
NetCtrl
5
Not Used 0x29 5
Speed Reference Speed Command 0x2A 8
5
Setting Reference Control and Run/Stop Control only can be done from keypad.
Therefore, NetRef and NetCtrl in Instance 21 and 101 are not available.
