9.4. Group FU2 (Functions Menu 2)
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9300 37632
FU2-00
Jump code
Jump to desired parameter 40 1 – 99
9301 37633
FU2-01
Last trip-1
Last trip of fault history - -
9302 37634
FU2-02
Last trip-2
Last trip-1 of fault history - -
9303 37635
FU2-03
Last trip-3
Last trip-2 of fault history - -
9304 37636
FU2-04
Last trip-4
Last trip-3 of fault history - -
9305 37637
FU2-05
Last trip-5
Last trip-4 of fault history - -
No
9306 37638
FU2-06
Erase trips
Erase fault history 0
Yes
0 – 1
9307 37639
FU2-07
Dwell time
Dwell time 0 0 – 100
9308 37640
FU2-08
Dwell Freq
Dwell frequency 500
FU1-32 –
FU1-30
No
930A 37642
FU2-10
Jump Freq
Skip frequencies selection 0
Yes
0 – 1
930B 37643
FU2-11
jump Lo 1
Setting of low frequency skip 1 1000
0 – FU2-
12
930C 37644
FU2-12
jump Hi 1
Setting of high frequency skip 1 1500
FU2-11 –
FU1-30
930D 37645
FU2-1
jump Lo 2
Setting of low frequency skip 2 2000
0 –FU2-
14
930E 37646
FU2-14
jump Hi 2
Setting of high frequency skip 2 2500
FU2-13 –
FU1-30
930F 37647
FU2-15
jump Lo 3
Setting of low frequency skip 3 3000
0 – FU2-
16
9310 37648
FU2-16
jump Hi 3
Setting of high frequency skip 3 3500
FU2-15 –
FU1-30
No
9314 37652
FU2-20
Power-on run
Restart after power supply fault 0
Yes
0 – 1
No
9315 37653
FU2-21
RST restart
Restart after fault reset 0
Yes
0 – 1
9316 37654
FU2-22
Speed Search
Speed search function
0 (Bit
setting)
0 – 15
(Bit
setting)
