SD450 - DEVICENET POWER ELECTRONICS
34
DEVICENET DATA TABLES
7.1.6. Class 29 – Control Supervisor Object
Class Code 0x29
Instance 1 (All Attributes are instance 1)
Attribute ID Attribute Name Access Method
3 Run 1 (Forward command) R/W
4 Run 2 (Reverse command) R/W
5 NetCtrl
7
R
6 State R
7 Running 1 (Forward running) R
8 Running 2 (Reverse running) R
9 Ready R
10 Faulted R
12 Fault Rst R/W
13 Fault Code R
15 Ctrl from Net R
Implemented for:
Service Name Code Service
Class Instance
Get_Attribute_Single 0x0E No Yes
Set_Attribute_Single 0x10 No Yes
7
NetRef Attribute: This Attribute setting determines the control location for the motor. This
value only can be set from keypad for safety reasons. Changing this one from the network
does not cause error and cannot affect the setting.
