POWER ELECTRONICS SD450 - DEVICENET
GROUP COM (COMMUNICATIONS). PARAMETER LIST
37
ENGLISH
8. GROUP COM (COMMUNICATIONS).
PARAMETER LIST
When connecting the DeviceNet optional board to the inverter a new
group of parameters related to the communications is available. This
one is the group COM and their parameters are described below.
Display Descrip. Range
Default
Value
Memory
Address
Function
Set
during
Run
COM ► Jump Code
00 1
Jump to
desired
parameter
1 to 99 1 9600
Any parameter of the group COM can
be selected directly from here without
scrolling up/down to other parameters.
You only need to introduce the
number of desired parameter and
press PROG key.
YES
COM ► Opt B/D
01 -
Communic.
Board type
Device
Net
- 9601
It displays the communications
optional board which is installed into
the inverter.
-
None
Command
Freq
COM ► Opt mode
02 -
Mode option
Cmd+
Freq
- 9602
None: Start/Stop command neither
speed reference will not be given from
the network.
Command: Start/Stop command will
be given from the network. The speed
reference will not be given from the
network.
Freq: The speed reference will be
given from the network. Start/Sop
command will not be given from the
network.
Cmd+Freq: Both signals will be given
from the network.
NO
COM ► Opt Version
03 -
Version - - 9603
It displays the used communications
protocol version.
-
COM ► MAC ID
10 63
DeviceNet
ID
0 – 63 63 960A
It allows identifying the equipment
number into the network assigned to
each device in a DeviceNet network.
YES
