Power Electronics SD450 Series User Manual

SD450 - DEVICENET POWER ELECTRONICS
40
ADDRESS LIST
Address Parameter Scale
Units
R/W Data value
Bit 0: Stop
Bit 1: Forward run
Bit 2: Reverse run
Bit 3: Fault reset
R/W
Bit 4: Emergency stop
- Bit 5: Not used
Bit 6 – 7: Reference
introduction
0: Terminals
1: Keypad
2: Reserve
3: Communication
Bit 8 – 14: Reference
frequency
0: DRV-00
1: Not used
2: Step frequency 1
3: Step frequency 2
4: Step frequency 3
5: Step frequency 4
6: Step frequency 5
7: Step frequency 6
8: Step frequency 7
9: Step frequency 8
10: Step frequency 9
11: Step frequency 10
12: Step frequency 11
13: Step frequency 12
14: Step frequency 13
15: Step frequency 14
16: Step frequency 15
17: Up speed
18: Down speed
19: Up/Down Zero
20 – 21: Reserve
22: Analogue V1
23: Analogue V1S
24: Analogue I
25: V1 + I
26: Pulses
27: Option
28: Communication
29: Option
30: Jog frequency
31: PID
0x0006 Run command
R
Bit 15: Network error
