Power Electronics SD450 Series User Manual

SD450 - DEVICENET POWER ELECTRONICS
58
ADDRESS LIST
Address Range
16 bit 10 bit
Screen Description
Default
value
Option Values
9452 37970
I/O-82
Relay On
On delay time of fault relay 0 0 – 9999
9453 37971
I/O-83
Relay Off
Off delay time of fault relay 0 0 – 9999
PowerOn
Fan
Run_Fan
9454 37972
I/O-84
Fan Con. Sel
Selection of cooling fan
operation
0
Temper_Fan
0 – 2
9455 37973
I/O-85
Fan Temp
Setting of inverter temperature 70 0 – 70
Speed
Percent
Bar
mBar
kPa
9456 37974
I/O-86
V1 Unit Sel
Selection of displaying units for
V1 signal
0
Pa
0 – 5
9457 37975
I/O-87
I Unit Sel
Selection of displaying units for
I signal
0 See I/O-86 0 – 5
9458 37976
I/O-88
PulseUnitSel
Selection of displaying units for
A0, B0 signal
0 See I/O-86 0 – 5
945A 37978
I/O-90
Inv No.
Slave number in
communication net
1 1 – 250
1200bps
2400bps
4800bps
9600bps
945B 37979
I/O-91
Baud rate
Transmission speed in
communication net
3
19200bps
0 - 4
None
Free Run
945C 37980
I/O-92
COM Lost Cmd
Stop mode after reference
signal loss in communication
net
0
Stop
0 – 2
945D 37981
I/O-93
COM Time Out
Setting of time to determine
speed reference signal loss
10 1 – 1200
945E 37982
I/O-94
Delay Time
Setting for RS232/RS485
communication
5 2 – 1000
945F 37983
I/O-95
In NO/NC Set
Logical function of digital inputs
0 (Bit
setting)
0 – 2047
(Bit
setting)
9460 37984
I/O-96
In CheckTime
Check time for digital inputs 1 1 - 1000
9461 37985
I/O-97
OH Trip Sel
Selection of over temperature
trip
2 (Bit
setting)
0 – 7 (Bit
setting)
9462 37986
I/O-98
MotTripTemp
Selection of over temperature
trip of the motor
110 0 – 255
