Part Number 6300-095D Page 24 of 43
mSensor and Hub LEDs
The mSensor and Hub have tri-colour LEDs that will exhibit varying behaviour as described below. The behaviour is the
same for both devices.
Colour State Description
Green Continuous Device is connected correctly.
For an mSensor, this indicates that the sensor is connected correctly to the
batteries being monitored and the battery voltages are appropriate.
Red Continuous Device is not connected correctly of has a fault.
For an mSensor, this may indicate that the sensor has detected a problem
with the wiring harness or battery.
Orange Continuous Device is in locate mode.
Green Single Flash Device is detected and operating as normal.
No warnings or alarms detected.
Orange Double Flash Device is receiving communication but has not been detected by the
PowerShield Controller.
White Continuous
Applies to Hub only.
Device is in boot loader mode and waiting for commands.
White Single Flash
Applies to Hub only.
Device is in boot loader mode and updating firmware.
Notes:
Single Flash = On for 0.25s, off for 3.75s.
Double Flash = On for 0.25s, off for 0.25s, on again for 0.25s and then off for 3.25s
.
