Appendix 9 – Controller Specifications
Configuration Interface
Web browser
Communication
Front
Rear
1000Base-T Ethernet (Service Port)
USB (Flash drive only)
LCD
1000Base-T Ethernet (PowerShield Link software, Modbus TCP, SNMP)
RS485 (optional)
Hub Ports
Capacity
Connection
Maximum Distance
8
1 PowerShield Hub and up to 32 PowerShield mSensors
RJ45 / CAT5 cable
50m / 165ft (between Controller and Hub)
Memory
2GB RAM
4GB Flash
Relays
Type
Rating
4
Single Pole Double Throw (SPDT)
1A @ 30VDC, resistive
Auxiliary Inputs
Type
2
Voltage Free / Dry Contact
Physical Dimensions
1U High 19” rack mount enclosure, mild steel with powder coat finish
Width: 430mm / 16.9 inches
Depth: 265mm / 10.4 inches
Height: 45mm / 1.8 inches
Weight: 3kg / 6.6lbs
The Controller must be installed in a location that allows 30mm space at
the top and sides of the unit for adequate air circulation.
Installation must allow unrestricted airflow.
Power Supply
Power Consumption
AC Model: 90V to 260Vac, 50/60Hz, 0.42A max.
24V DC Model: 18V to 30Vdc, 1.1A max.
48V DC Model: 35V to 60Vdc, 0.52A max.
110V DC Model: 80V to 150Vdc, 0.22A max.
Typical 5W + 1.6W per Hub
Max. 6W + 1.8W per Hub
Environment
Indoor use only, Overvoltage Category II, Pollution Degree 2
Operating Temperature: 0°C to 50°C / 32F to 122F
Storage Temperature: 0°C to 70°C / 32F to 158F
Altitude: 2000m max.
Specifications subject to change.
