Appendix 11 – mSensor Specifications
Block Inputs
Block Type
1 or 2 (depends if using a single or dual mSensor)
1.2V NiCad, 2V, 4V, 6V, 8V, 12V, 16V Lead Acid
Nominal Voltage
1
Voltage Range
Voltage Resolution
Voltage Accuracy
Ohmic Range
2
Ohmic Resolution
Ohmic Accuracy
Maximum Input
NiCad
0.8 – 1.9V
1mV dc, 1mV ac
±0.3%
0.1 – 5mΩ
1uΩ
±2.5% + ±15uΩ
±5V
2V
1.6 – 2.6V
1mV dc, 1mV ac
±0.3%
0.1 – 5mΩ
1uΩ
±2.5% + ±15uΩ
±6V
6V
4.8 – 7.8V
5mV dc, 1mV ac
±0.2%
0.5 – 20mΩ
1uΩ
±2.5% + ±25uΩ
±25V
12V
9.6 – 15.6V
5mV dc, 1mV ac
±0.2%
1.0 – 40mΩ
1uΩ
±2.5% + ±25uΩ
±65V
Temperature Inputs
Type
Range
Accuracy
3
/ Resolution
Maximum Distance
1 per Block
Thermistor, located on Negative Terminal of Block
-10°C to 70°C / 14F to 158F
±1°C, 0.1°C
15m / 50ft
Communication Interface
Connection
Type
Protocol
Maximum Distance
Isolation
4P4C Modular Jack / 4-core flat modular cable
Proprietary differential bus
Modbus
25m / 82ft (total length of wiring from Hub to last mSensor)
UL certified to 600V DC (internal optical isolation)
Physical Dimensions
Width: 106mm / 4.2 inches
Depth: 75mm / 3.0 inches
Height: 25mm / 1.0 inch
Weight: 161g / 0.4lbs
Power Supply
Nominal Supply Current
4
NiCad
50mA
2V
30mA
6V
18mA
12V
18mA
Environment
Indoor use only, Overvoltage Category 0, Pollution Degree 2
Operating Temperature: 0°C to 50°C / 32F to 122F
Storage Temperature: -10°C to 70°C / 14F to 158F
Altitude: 2000m max.
Specifications subject to change.
1. Most common models. Other models available on request.
2. NiCad single mSensor cannot perform ohmic measurement.
3. Over the range 0°C - 50°C.
4. From block(s) being monitored.
