Appendix 2 – LED Behaviour
PowerShield Controller LEDs
The PowerShield Controller has LEDs on the front panel for on-site information. They will exhibit varying behaviour as
described below:
Name Colour Description
Controller Power Green On continuously when powered.
Controller Alarm Red On continuously if the PowerShield Controller has an
internal system fault.
Should be off under normal circumstances.
LAN Speed Green On if LAN connection is operating at 1Gbps.
LAN Link/Activity Green On if LAN Ethernet link is up.
Flashes during activity.
Battery Alarm Red On if there is a battery or string alarm.
Battery Warning Orange On if there is a battery or string warning.
Battery Discharge Orange On if all strings are in discharge.
Flashes if one or more strings in discharge.
Battery Float Orange On if all strings are in float.
Flashes if one or more strings in float.
USB Status Orange Off if there is no external USB device present or when
it is safe to unplug the device.
On if the USB device is ready for use.
This state should occur shortly after a device has been
plugged in and detected successfully.
Flashes during activity.
Note:
Pressing the USB Save button also affects the state of
the USB Status LED.
