PowerShield 8 - Appendix 10 - Hub Specifications

___________________________________________________________________________________________________________
Part Number 6300-095D Page 38 of 43
Appendix 10 – Hub Specifications
Block Inputs
Type
up to 64 (via dual PowerShield mSensors)
PowerShield mSensor
Current Inputs
Type
Range
Maximum Distance
1 (provides string DC & AC current)
Hall Effect
0A to ±2000A (depends on Current Transducer model used)
3m / 10ft
Temperature Inputs
Type
Range
Maximum Distance
2
Thermistor
-10°C to 80°C / 14F to 176F
15m / 50ft
Auxiliary Inputs
Type
2
Voltage Free / Dry Contact
Humidity
Type
Range
1
On-board sensor
0% to 100% Relative Humidity
Communication Interface
Connection
Type
Protocol
Maximum Distance
RJ45 / CAT5 cable
Proprietary differential bus
Modbus
25m / 82ft (total length of wiring from Hub to last mSensor)
Physical Dimensions
Width: 120mm / 4.7 inches
Depth: 107mm / 4.2 inches
Height: 25mm / 1.0 inch
Weight: 177g / 0.4lbs
Power Supply
24V DC via PowerShield Controller hub port
Environment
Indoor use only, Overvoltage Category II, Pollution Degree 2
Operating Temperature: -10°C to 50°C / 14F to 122F
Storage Temperature: -10°C to 80°C / 14F to 176F
Altitude: 2000m max.
Specifications subject to change
