2.
Install the fan onto the top cover so that the embossed air flow indicator arrow
points into the MC housing (the fan must push the air into to MC housing). If replacing
the older fan with the newer fan, the new fan cable routing has changed. Feed the
power cable thru the right cable housing opening (not the left opening) and install the
new fan.
3.
Reinstall the fan grill onto the fan and top cover . Secure with the four #2
screws.
4. Reconnect the fan power cable and install the top cover onto the MC housing. Make
sure that the power cable is not pinched or damaged while snapping the top cover
into the housing tabs. Secure the top cover to the MC housing cover using the one
screw fastener .
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 123
6 Replacement Procedures
Motor Controller Fan Replacement
