1. Switch the power OFF and unplug
1
the power cord.
2. Remove the hood cover, see "Hood Cover Replacement" on page 82, and left/right
Trim Landing covers, see "Trim Landing Covers Replacement" on page 85.
3. Remove the Take-up Roller, see "Take-up Roller Replacement" on page 144.
4. Remove the Drive Roller, see "Drive Roller Replacement" on page 139.
5. Repeat this procedure to remove the right and left side rear deck fasteners and hard-
ware:
a. Remove the left/right rear deck #3 Phillips screws (4x) and washers (4x). The
rear deck fasteners are screwed into the pivot assembly bolts. Be aware that
the pivot assembly has two press fit fastener nuts that could fall from the hous-
ing when the bolts are removed. If this occurs, reinsert the nut into the pivot
housing. Retain part(s) and/or fastener(s) for installation.
b. If the deck is being flipped or replaced, remove the left/right #3 Phillips screws
(2x) and belt trackers (2x). Retain part(s) and/or fastener(s) for installation.
c. If the deck is being flipped or replaced, use a plastic putty knife sharp edge to
pry up and remove the pine tree clips (2x). Alternatively, you can pop the pine
tree clips from the back side after the deck is removed. Retain part(s) and/or
fastener(s) for installation.
TIP: Avoid applying heavy downward pressure on the pivot assembly bolts while
removing. Pressing down to hard could push the nuts out of the pivot housing. If this
occurs, .reinstall the nut into the pivot housing.
1
Disconnect a device power cord plug or cable connector from the power receptacle or out-
let.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 150
6 Replacement Procedures
Running Belt and Deck Replacement Procedure
