© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 93
Replacing the Incline Motor
Note: The replacement incline motor must be calibrated prior to installation.
1 Set the treadmill’s circuit breaker in the off position and remove the
AC line cord from the AC outlet.
2 Disconnect the incline motor connector from the INCLINE connector on
the power control module. See Figures Below (TRM Lift Motor and Lower
Control Module).
